Understanding water tank’s role on liquid ring vacuum pump systems

Reading time 5 minutes (717 words)

Liquid ring vacuum pumps cannot operate without water or another service liquid, which underscores the necessity of a water tank. The water tank is a key part of the system, designed to store and control the amount of the service liquid used. Let’s dive into some straightforward insights on why it is so important and how it impacts your system’s operation.

Optimal water supply and perfect water balance

Picture the water tank as the lifeline of your liquid ring pump. If the two are not connected, the pump is unable to create vacuum. To ensure a smooth supply of water to the pump, we recommend placing the water tank one meter above the pump, allowing gravity to facilitate the flow of water naturally. Keep in mind that is very important to balance water levels carefully to prevent the following two scenarios:

• A dry disaster: Operating the pump with insufficient water will result in overheating, leaks, wear, damage to the seals and overall a less efficient pump.
• An overloaded pump: Too much water means trouble too. Imagine filling the tank to its utmost capacity and then activating the pump. The result? The motor experiences undue strain. It’s like trying to run through a pool—you’re going to feel the resistance. If there is too much strain on the pump’s motor, it compromises the system’s efficiency, safety, and longevity.

So how do you strike the perfect water balance? It’s like packing a suitcase: Enough to stay clean, but not too much to be weighed down.

Sizing your water tank smartly

Another crucial aspect to consider is the selection of the right-sized water tank. When determining the appropriate dimensions for your water tank, you need to take into account:

• Operational time vs. weight: You want a large enough tank to keep refilling to a minimum but not so hefty that your truck grumbles under the weight.
• Consumption rate factors: This isn’t just about the pump size or how fast it runs. Even the weather plays a role. Imagine a hot day when a glass of water seems to evaporate almost instantly—that’s how your pump functions on a busy summer workday.
• Truck constraints: While a larger tank might seem ideal, it’s essential to consider the truck’s capacity. If the truck is unable to support the weight, acknowledging and adhering to its limitations is crucial.

Where to place your water tank?

Selecting the placement of your water tank it’s a strategical decision. Choosing the right spot can greatly influence both vehicle performance and operational efficiency. Typically, there are three common locations for mounting the tank:

• Water tank outside the vacuum tank : This method allows easier maintenance and improves access. But reduces available space for other vital equipment, leaves the tank vulnerable to environmental damage and impacts the truck’s airflow, potentially leading to a decrease in fuel efficiency.

• Water tank inside vacuun tank with separation: This setup saves space on the truck by combining two tanks into one area, giving you more room for other equipment. It also shields the water tank from weather and damage since it’s tucked away inside the vacuum tank. On the downside, it’s harder to get to the water tank when you need to fix or clean it, which might take more work and time.

• Water tank inside vacuum tank and air/flow separation outside: This approach maximizes internal space efficiency, enabling more equipment to fit on the truck. It also reduces the need for a large water tank, which means you have the capacity to carry larger loads on the truck.

Other considerations:

• Water quality is king: Imagine taking a bath and then watching someone toss in a bucket of mud. Your pump feels the same way about dirty water. A little plumbing finesse, making sure the water return is above potential muck and having a way to drain everything out, goes a long way.
• Cold weather challenges: Winter isn’t fun for water-based systems. To avoid a popsicle pump, drain it when idle, or treat the water to some antifreeze if it has to work in the chill.

In essence, managing your water tank is a lot about common sense mixed with a pinch of technical know-how. By paying attention to these points and utilizing tools like our Solution Finder, you set up your liquid ring vacuum pump for success, ensuring it runs smoothly, efficiently, and for many years to come.
